Name: TAPPI T498 Tissue Softness Tester with 10-1000mN Measuring Range 1.2mm/s Test Speed and 15s Measurement Time
Brand: SKYLINE INSTRUMENTS CO.,LTD
SKU: SL-P22
Price: 4,500.00 USD
Availability: InStock

홈 제품 소개 실험실 실험 장비

TAPPI T498 Tissue Softness Tester with 10-1000mN Measuring Range 1.2mm/s Test Speed and 15s Measurement Time

제품 상세 정보:

원래 장소:	중국
브랜드 이름:	SKYLIE
인증:	CE, Calibration Certificate, Rosh, CO...
모델 번호:	SL-P22

결제 및 배송 조건:

최소 주문 수량:	1
포장 세부 사항:	수출 합판 패키지
배달 시간:	근무일 15 일
지불 조건:	L/C, D/P, D/A, T/T, Western Union, MoneyGram
공급 능력:	20-30 /월

접촉

상세 제품 설명

측정 범위:	(10 ~ 1000)mN	테스트 속도:	1.2mm/초
측정시간:	15s	결의안:	1mN
정확도:	± 1%	프로브 침투 깊이:	8 +0.5mm
샘플 플랫폼 좁은 폭:	5mm, 6.35mm, 10mm, 20mm	샘플 테이블 슬릿 양쪽의 평행도 오류:	≤0.05mm
전원 공급기:	AC 220V±22V, 50Hz
강조하다:	10-1000mN Measuring Range Tissue Softness Tester , 1.2mm/s Test Speed TAPPI T498 Test Machine , 15s Measurement Time Softness Testing Equipment

TAPPI T498 Tissue Softness Test Machine

Product Overview

The Tissue Softness Tester is a precision instrument that simulates hand feel to measure material softness. Designed in compliance with GB8942 national standard for paper softness determination, it's ideal for testing medium and high-grade toilet paper, tobacco sheets, fabrics, and similar sheet materials.

Key Features

Microcomputer-controlled digital test system with touch screen interface
Bilingual (Chinese/English) operating system with intuitive controls
Advanced technology with reliable performance and easy operation
Ideal for paper manufacturing, scientific research, and quality inspection

Test Principle

The instrument measures softness by pressing a plate probe into the sample to a depth of approximately 8mm. The softness value (in millinewtons) represents the sum of the sample's maximum anti-bending force vector and the friction between sample and gap. Lower values indicate softer materials.

Compliance Standards

GB/T 8942 QB/T 1060 ASTM D2923 ASTM D6828-02 TAPPI T498 INDA IST 90.3 EDANA WSP 90.3

Technical Specifications

Parameter	Specification
Measuring range	(10 ~ 1000) mN
Test speed	1.2mm/s
Measurement time	15s
Resolution	1mN
Accuracy	±1%
Probe penetration depth	8 +0.5mm
Sample platform narrow width	5mm, 6.35mm, 10mm, 20mm
Parallelism error on both sides of the sample table slit	≤0.05mm
Display	5-inch touch screen with curve display (50,000 hour lifespan)
Power supply	AC 220V ± 22V, 50Hz
Transport packaging	Wooden outer box with internal buffer material
