| 브랜드 이름: | Skyline |
| 모델 번호: | SL-FL609 |
| 모크: | 1 |
| 가격: | 협상 가능 |
| 지불 조건: | T/T, L/C, D/A, D/P, Western Union, MoneyGram, 현금 |
| 공급 능력: | 30 단위 / 월 |
| Parameter | Specification |
|---|---|
| Weight of pendulum | 1500g ± 30g |
| Distance from the center of gravity of pendulum to the end | 410mm ± 5mm |
| The static pressure of the rubber sheet on the ground | 22.2N ± 0.5N |
| Sliding length of pendulum on the road surface | 126mm ± 1mm |
| Distance from the lower edge of the rubber sheet to the swing center of the pendulum | 510mm ± 2mm |
| Dimension of rubber sheet | 6.35mm x 25.4mm x 76.2mm |
| Shore hardness of rubber sheet | 55 ± 5 HD |
| Pointer | Weight ≤85g, length 300mm ± 1mm |
| The Angle between the rubber sheet and the horizontal | 26 ± 3° |
| Machine Dimension | 620*450*590mm (About 14kg) |
