| Parameter | IZOD Impact | Charpy Impact |
|---|---|---|
| Pendulum Energy | (5.5D) 2.75J, 5.5J | 1J, 2J, 4J, 5J |
| Impact Speed | 3.5 m/s | 2.9 m/s |
| Pendulum Center to Impact Blade Distance | 335 mm | 230 mm |
| Impact Blade Edge Fillet Radius | R = 0.8 ± 0.2 mm | R = 2 ± 0.5 mm |
| Additional Specifications | Impact blade to upper plane distance of jaw: 22mm | Angle of the Impact blade: 30° ± 1° |
| Display Mode | Color touch screen (Chinese and English) | |
| Angle Sensor Brand & Accuracy | Original imported Omron encoder, accuracy to 0.01° | |
| Pendulum Angle | 150° | |
| Energy Display Accuracy | 0.01 J | |
| Machine Weight | 85 kg | |
| Power Supply Voltage | AC220V ± 10% 50HZ | |
